| Артикул | NM24P |
| Вспомогательные переключатели | Нет |
| Кабель | 1 м, 3 x 0.75 мм |
| Крутящий момент | 10 Нм |
| Питание | 24 В~/= |
| Площадь заслонки | 2 м |
| Присоединение | Универсальный захват |
| Серия | NM_P |
| Управление | Откр/Закр 3-поз. |
| Electrical data | |
|---|---|
| Nominal voltage | AC/DC 24 V |
| Nominal voltage frequency | 50/60 Hz |
| Nominal voltage range | AC 19.2...28.8 V / DC 19.2...28.8 V |
| Power consumption in operation | 1.5 W |
| Power consumption at rest | 0.2 W |
| Power consumption for wire sizing | 4 VA |
| Connection supply | Cable 1 m, 3 x 0.75 mm (halogen-free) |
| Functional data | |
| Torque | motor Min. 10 Nm |
| Direction of rotation motor | As an option with switch 0 (counter-clockwise rotation) / 1 (clockwise rotation) |
| Manual override | Gear disengagement with push-button, can be locked |
| Angle of rotation | Max. 95°, can be limited on both sides with adjustable mechanical end stops |
| Running time motor | 150 s / 90° |
| Sound power level motor max. | 35 dB (A) |
| Spindle driver | Universal spindle clamp 10...20 mm |
| Position indication | Mechanical, pluggable |
| Safety | |
| Protection class | III Safety extra-low voltage |
| Degree of protection | IP66 + IP67 |
| EMC | CE according to 2004/108/EC |
| Principle of operation T | ype 1 |
| Rated impulse voltage | 0.8 kV |
| Control pollution degree | 4 |
| Ambient temperature | –30 ... +50°C |
| Non-operating temperature | –40 ... +80°C |
| Ambient humidity | 100% r.h. |
| Maintenance | Maintenance-free |
| Weight | |
| Weight | 1.3 kg |
